Loudspeaker NSC (951055)
Fiamm Loudspeaker for PS10 acoustic signalling sets.
The NSC loudspeaker is fitted with a performance neodymium magnet. This loudspeaker can be mounted on small vehicles vehicles such cars, motorbikes and vans.
The loudspeaker has a high resistance from water and dust infiltration ( IP66).
The speaker is homologated with the electronic modules PS10. The PS10 systems are homologated for emergency vehicles in Italy, Germany, France, Switzerland, France and other countires
The PS10 system is approved against electromagnetic disturb in conformity to the restrictive standard CEE 2009/19 and ECE Reg.10 and he can be used in every country on emergency and security vehicles.
Please note: You will need a 12v or 24v power supply (battery) on board for this system.
Basic Technical Info
| Nominal Voltage |
12Vdc / 24Vdc |
| Voltage Range |
10-16V / 20-32V |
| Impedance |
4 Ohm |
| Sound pressure / Decibels (at 2 meters) |
113 dB |
| Nominal Power |
20 W |
| Peak Power |
30 W |
| Frequency range |
1000-5200 Hz |
| Operating temperatures (Celcius) |
-40 •C to +80 •C |
| Storage temperatures (Celcius) |
-40 •C to +95 •C |
| IP code (Ingress Protection) |
IP67 |
| Corrosion Resistance (Salt spray test in hours) |
> 480 Hrs |
| Operating relative humidity (%) |
30% - 80% |
| Continuous operating time (minutes) |
120 min. |
| Weight (grams) |
475 gr. |
| Main Material |
ABS, Neodymium Magnet |
| Mainly suitable for vehicles |
Motorcycle, Car, Van |
| HS Code |
85123090 |
| Registrations |
- CEE 2009/19
- R. 10/03 ECE/ONU |
| Production conformities |
- ISO/TS 16949
- ISO 9001
- ISO 14001 |
