FIAMM Jericho DIN / M12 Thread
(FIA928051Z)
The FIAMM Jericho Air horn is a compact Truck air horn for professional use.
Air horn with built-in electronic valve for trucks and buses.
Fiamm supplies several variants of this type of horn, with both electrical and pneumatic connections differing.
This Jericho is equipped with a DIN connector and M12x1.5 internal air connection.
Please note: an m12 coupling can be ordered with this product.
Delivery:
1x Jericho Air horn
1x Connection Cable
| Productinfo |
| Material |
PA66 , Steel |
| Measurements (HxWxL) |
20cm x 12,5 cm x 9,5cm |
| Weight |
390 gr. |
| Voltage |
24v |
| Ampere |
0,8 A |
| Air Pressure (Bar) |
4-8 bar (amount of pressure influences dB's) |
| Soud Pressure (at 2m) |
118 dB |
| Fiamm Code |
928051Z |
| Connector Type: |
DIN (see download) |
| Air Connection |
M12x1.5 thread (Female) |
| EU-Registration |
10 ECE
28 ECE |
| Made In |
Italy |
| HS Code |
85123090 |
Attention:
1. For this horn you need air on board. This must produce at least 4bar - 8bar pressure.
2. For this horn you need a 24V electrical power supply on board.
